Product introduction
High Efficiency 1 Ton Agitator Type V Type Powder Mixer For Chemical Powder
V type mixer is the most common powder and granular material mixer in the world. It has the advantages of simple structure, easy operation, convenient maintenance and cleaning, and fast mixing speed.
The machine two cylinder length is not equal to the design of asymmetric, when the mixer rotates the material from dispersion to combination, from combination to dispersion, to promote the material transverse exchange, each turn of transverse force about 25% of the material flow from one cylinder to another cylinder, so that the material transverse radial mixing, dispersion combination each other, so that the material to achieve very uniform mixing effect.
No mechanical extrusion and strong wear, can keep the material particle integrity. Polishing inside and outside the cylinder, smooth transition, no dead Angle, can avoid cross contamination of materials.
Technical parameters
We produce different specifications of mixers, if you want to customize your machine, please contact us.
| Model | V-2000 |
| Maximum loading(L) | 1000 |
| Total volume(L) | 2000 |
| Diameter(mm) | 1000 |
| Power(kw) | 11 |
| Auxiliary stirring power(kw) | 2.2 |
| Adjustable frequency(rpm) | 3-17 |
| Surface treatment | Mirror Polishing or Sandblast |
| Additional Capabilities | Drying |
| Material | SUS304, SUS316L |
Feature
1) High mixing uniformity. Due to the use of two cylinders of different length structure, there is a time difference in the material flow inside the cylinder, so it has a very high mixing efficiency and mixing uniformity.
2) No residue, no cross contamination. There is no dead Angle between the inside of the cylinder and the contact part of the material, the mixing process is mild, no segregation, complete discharge, no residue, no cross contamination phenomenon.
3) V type mixer can vacuum suction and seal butterfly valve discharge, the implementation of dust-free operation.
4) V type mixer consists of two asymmetric cylinders, the material can be used for vertical and horizontal flow, mixing uniformity can reach more than 99%.
5) The cylinder is made of stainless steel plate, the inner and outer walls are polished, clean and sanitary, and do not accumulate material.
6) V type mixer is simple to operate, can be equipped with timing operation, also can be used for dot operation.
Application
This machine is mainly used in various industries for mixing the powder, granule or other materials.Food, spices, additive, vitamins and all kinds of sugar, flour, coffee powder, etc.;Medicine: capsules, spices, Chinese traditional medicine powder or granule of Chinese herbal medicine, etc.;Feed, fish, poultry, wild animal, bird feed, etc.;Chemical, plastic particles, masterbatch, chemical materials, etc.;Industry: iron powder, copper powder, magnesium powder, etc;
